Stable Solar Photovoltaic Module , 40 W Solar Energy Panels Easy Installation

Product Categories

Suzhou Jun Hui Import and export trade Co., Ltd.

Contact Now

Stable Solar Photovoltaic Module , 40 W Solar Energy Panels Easy Installation

Name: Stable Solar Photovoltaic Module 40 W Solar Energy Panels Easy Installation
Brand: Yingli/Jinko
Price: 1 USD

Brand Name : Yingli/Jinko

Certification : ISO9001/CE

Place of Origin : China

MOQ : 50 Pieces

Price : Negotiation

Payment Terms : T/T、L/C、West Union

Supply Ability : 5000000 Watt/Watts per Month

Delivery Time : Shipped in 7 days after payment

Packaging Details : In well protected carton or wooden box with pallets. 26pcs per pallet, 380pcs fill into 20GP, 820pcs fill into 40HQ

Grade : A-Grade Degree

Hscode : 8541402000

Specification : CE

Avaliable : OEM

Color : Duck blue

Size : 1950*990*50mm

Weight : 18.6kg

Number of Cells : 72pcs

Contact Now

Cheaper Price & Higher Quality Ploy Sloar Panel 40w From China Manufacturer

Specifications

Hot sale 290w poly solar panel with high efficiency
1) 14.5% efficency
2) easy to install
3) offer OEM
4) TUV/CEC/ISO

Recommended applications:

1. Residential roof top systems
2. On-grid utility systems
3. commercial or industrial systems

Warranty

5years product warranty
90% power output 10 years
80% power output 25 years

Solar Panel Parameters	RSM72-156P/290W
Optimized working voltage	36.40V
Optimized working current	7.96A
Open circuit voltage	44.4V
Short circuit current	8.43A
Nominal power	290W
Module efficiency	15.00%
Operating temperature	-40°C to+85°C
Maximum system voltage	1000VDC(IEC)/600VDC(UL)
Series fuse rated value	20A
Power tolerance	±3%
Cell specification	156×156mm (6inch)
Arrangement quantity	72(6×12)
Solar panel dimension	195099050
Weight	22.0kg
Glass specification	3.2mm(0.13inch) tempered glass
Frame	Anodised aluminium alloy
Rated operating temperature	45±2°C
Pmax temperature parameter	-(0.48±0.05)%/°C
Voc temperature coefficient:	-(0.34±0.1)%/°C
Isc temperature coefficient	0.04±0.01%/°C
Dimension of pallet	200011501150mm
Quantity in a 20’ container	14pallet; 21pcs/pallet;294pcs
Quantity in a 40’ container	28pallet;21pcs/pallet;588pcs
Notic:Data under standard testing condition (STC):1000W/m2,AM1.5,25°C.
